High Quality Glass Insulator - Composite Pin Insulator – Yongjiu Detail:

Composite pin insulator is made of glass fiber epoxy core rod, silicone rubber shed and metal fittings.
The silicone rubber shed adopt the whole packing pressure technique, and then to solve the key problem – interface electric spark puncture, which would affect the reliability of composite insulator.
The connection of the glass fiber rod and metal fittings adopts the pressure welding technique of the international advanced level and have the full automatic sound wave detection of defects system, high intension, beautiful outline, small volume, light weight, and the metal fitting of galvanization can corrosion prevention and exchange used with porcelain insulator.
This product is reliable structure, can’t damage the core rod, and take full advantage of the mechanical strength.
The dimension can be customized as per client’s requirement.
Material of end fittings: #45 forged steel, hot dip galvanizedthickness of the galvanization: ≥86μm
Material of the core: Epoxy & glass fiber (ECR type or FRP type).
Material of the weather sheds: HTV silicone, color grey
Service Cut Out Fuse JG Series

Item No.

Dimensions

Mechanical

Electrical



Height
(mm)

Min Dry Arcing Distance

(mm)

Min Creepage Distance

(mm)

Diameter of the rod

(mm)

Number of sheds

Max Design Cantilever Load

(MDCL) (kN)

Specified Cantilever Load

(SCL) (kN)

Rated Voltage kV

Highest Voltage  kV

Lightning Impulse Withstand BIL  kV

Power Frequency Flashover Voltage

(Dry/Wet) kV

FPQ-11/4

235

200

345

24

2

4

2

11

12

95

38

FPQ-18/5

245

210

450

24

3

5

2.5

18

15

95

45/40

FPQ-27/3

340

290

660

24

5

3

1.5

24

27

160

60

FPQ-33/12.5

430

370

1040

38

5

12.5

6.25

33

36

230

95

Yongjiu Electric Power Fitting Co., Ltd, is a primary domestic professional manufacturerof electric power fitting and cable accessory. Our main products are cable connector, line fitting,(Copper Aluminium and iron), cable accessory, plastic products, power tools.fuse(LV& HV), light arrester and insulator with approved quality complying with IS09001/2000.
Our company was founded in 1989. Our company is located in Liushi Town, Wenzhou , which is the center of electrical equipment in China. It is about 15 km from Wenzhou Airport and Railway Station.
Covering an area of 20,000 square meters, our company has more than 300 skiklled staff, including 38 senior & intermediate technical personnel and administrativepersonnel.
Focussing attention on renovation, our company has sucessfully developed more than 500 series products. With intermationally advanced machinery processing facilities, our company is capable of producing various electric power fitting and cable accessory to meet customers’ special requirement.
Our products have been exported to more than 40 countries and they are sold well in those coutries and regions.
We enjoy a good reputation among customers due to unique styles and consistently high quality. Adheringto the principle of “Sincere Service, Faithful Reputaitob and Top Priority of Customers”, we always try our best to provide excellent after-sales service.
We sincerely welcome clients all over the world to establish business relationships with us for a mutual development.


Product detail pictures:

High Quality Glass Insulator - Composite Pin Insulator – Yongjiu detail pictures
